Hanwha Vision HCF-8011RV 5MP IR Analog HD Fisheye Camera
525.00$
In stock
Hanwha Vision HCF-8011RV 5MP IR Analog HD Fisheye Camera
Key Features
- 5MP (2560×1944) resolution
- 20FPS @ 5MP
- IR Viewable Length: 10m (32.8ft)
- BLC
- Day & Night (ICR)
- WDR 120dB
- Coaxial communication (ACP / Coaxitron)
- Selectable universal output (AHD / CVBS)
- IP66/IK10
- Power: 12VDC / 24VAC
- Operating Temperature: -30°C ~ +55°C (-22°F ~ +131°F)
- Hard coated dome bubble
- White color
Video
| Imaging Device | Size | 1/2.9″ |
| Type | CMOS | |
| Resolution | 2560×1944 | |
| Max. Framerate(NTSC/PAL) | 20fps | |
| Min. Illumination | Color(1/30sec, 30IRE) | 0.5 |
| BW(1/30sec, 30IRE) | 0.005 | |
| Video Out | BNC: AHD/TVI/CVI/CVBS Selectable | |
| Video Transmission Distance | 300m(5C2V Coaxial Cable) | |
Lens
| Focal Length (mm) | 1.16 | |
| Max Aperture Ratio (F number) | Wide | 2.25 |
| Angular Field of View | Horizontal | 180° |
| Vertical | 180° | |
| Min. Object Distance | 0.2m(0.66ft) | |
Operational
| Day & Night | Auto(ICR) | |
| Backlight Compensation | BLC, WDR, SSDR | |
| Wide Dynamic Range (dB) | 120 | |
| Digital Noise Reduction | SSNRⅤ | |
| Gain Control | Low, Middle, High | |
| White Balance | ATW, AWC, Manual, Indoor, Outdoor | |
| Electronic Shutter | Mode | Minimum, Maximum, Anti flicker |
| Speed Range | 1/30~1/50,000sec | |
| Video Rotation | Flip, Mirror, Hallway view(90°/270°) | |
| IR Viewable Length | 10m(32.81ft) | |
| Coaxial Protocol | ACP, CVBS | |
Environmental & Electrical
| Operating Condition | Temperature | -30°C~+55°C(-22°F~+131°F) |
| Humidity | 0~90% RH(non-condensing) | |
| Storage Condition | Temperature | -50°C~+60°C |
| Humidity | 0~90% RH(non-condensing) | |
| Input Voltage | 24VAC, 12VDC | |
| Power Consumption | 12VDC | 6.5W |
| 24VAC | 5.4W | |
Mechanical
| Color | White | |
| Material | Aluminum | |
| RAL Code | RAL9003 | |
| Product Dimensions | ø145.9×65.8mm(ø5.74×2.59″) | |
| Product Weight | 720g(1.59lb) | |
| Weight | 2 lbs |
|---|---|
| Dimensions | 6 × 3 × 3 in |
| Brands | |
| Color | |
| Camera Style | |
| Lens-type | |
| Resolution | |
| Material |
